Ice-O-Matic Undercounter Ice Maker

UCG135 - Ice Machine

Ideal ice machine for any under-counter or bar application. Constructed from sturdy, corrosion-resistant stainless steel and fingerprint-proof plastic. Easily adjust the thickness of your ice cube from the front of the ice machine! Front air discharge design for compact spaces.

Produces up to 57kg of ice per day with built-in 22Kg Ice storage bin.

UCG105 - UCG135-1
shot style icon
UCG105 - UCG135-1
shot style icon

Key Features

Integrated Storage

Ice making and storage in one small ice machine that fits under most counters.

Sleek, Compact Design

Space-saving undercounter footprint with contemporary styling.

Superior Construction

Durable corrosion-resistant stainless steel on the inside and a durable stainless finish and industrial-grade fingerprint-proof plastic.

Bistrot Cubes

Crystal-clear, long-lasting, shot-style ice cubes.

Front-Panel Thermostatic Controls

Easy to access thermostatic controls for adjusting key working parameters of the machine.

Removable Air Filter

The all new removable Air filter  allows end-user to easily clean as part of the routine cleaning process.  This helps to ensure it is always operating to its optimum performance and extends the expected life-span of the machine.

Benefits

Horizontal spray technology

Each ice cube is individually produced using horizontal spray technology.

Tech Specs

Dimensions

Width: 467mm

Depth: 570mm

Height: 790mm

Hydraulic

Minimum allowed supply water pressure: 1.0-4.0 bar

Maximum incoming water pressure: 4.1 bar

Minimum incoming water temperature: 4.5 °C

Maximum incoming water temperature: 38°C

Electrical

Amps Required: 13A 1 Phase

Performance

Ice Cube Style: Shot 20g

Bin Storage: 22kg

Net Weight: 45kg

Ice Production 10°C Water 10°C Air: 57kg/24hr

Ice Production 15°C Water 21°C Air: 55kg/24hr

Components

Condensing Unit: Air

Air Cooled Units: Yes

External Drain Pump: Optional

Downloads for UCG135

UCG135 Specification Sheet

UCG135 Installation Manual

UCG135 Spare Parts Manual
